RXR-M150GD
GUOXING
| Quantity: | |
|---|---|
4wd Diesel Remote Control Water Gun Intelligent Fire Fighting Robots RXR-M150GD
Ultra Powerful Diesel Engine: 46KW high-performance engine for strong mobility and fire suppression
Ultra High Flow Firefighting System: 150L/s water & foam output
Long Range Operation: Fire water jet up to 95 meters
Extreme Terrain Adaptability: Forest, rubble, stairs, narrow passages
Heavy Duty Structure: 1100kg reinforced chassis design
Long Distance Remote Control: 1000m wireless control range
46KW high-performance engine for strong mobility and continuous operation
Supports heavy-load firefighting systems and all-terrain movement
Wide crawler enables passage over rough terrain, mud, stairs, and narrow doors
Can rotate in place for tight environments
Max obstacle height: 430mm
Climb slopes/stairs up to 40°
Dual-purpose water & foam cannon
Flow rate: 150L/s
Effective shooting range: Water ≥95m, Foam ≥90m
Integrated remote control of water cannon and robot movement
Wireless control up to 1000 meters
Panel control for precise maneuvering
Real-time monitoring and operation feedback
Detects gases and hazardous substances at the fire scene
Provides real-time environmental data for safe firefighting
Water mist self-protection system for robot safety
LED lights for low-visibility operation (Front: 20W ×2, Rear: 10W ×2)
Optional electric winch with >1-ton pulling force
Hydraulic power supply: 20L/min @ 210 bar for attachments
Swivel angle: 340°
Pitching angle: -30° to +90°
Roll stability angle: 30°
Driving speed: 0–10 km/h
Traction: 6KN
Suitable for Forest Firefighting, Urban Firefighting, Industrial Hazards, Search & Rescue, and Defense Operations
Supports integration of AI sensors, thermal cameras, and other firefighting equipment
Water mist self-protection
360 degree monitor
430MM obstacle height
40° max climbing
Import TFT cannon
Large Flow 150L/S
Chassis Parameters | Fire extinguishing system parameters | ||
Dimension | 2000×1100×1400（含水炮）include water cannon | Water cannon | Water and foam dual purpose, shooting range ≥95m, flow rate 120L/s, water cannon and robot remote control integrated in one |
Total weight | 1100kg | Flow | 150L/S water，150L/S foam |
Obstacle height | 430mm | Shooting range | 95m water，90m foam |
Ground clearance | 200mm | Pitch angle negative | negative 30°-positive 90 |
Climb ability | 40° slope or stairs | Swivel angle | 340° |
Roll stability angle | 30° | Auxiliary system parameters | |
Remote distance | 1000m(panel control) | Lighting | LED 灯，前 20Wx2 后 10Wx2 LED light, front 20Wx2 rear 10Wx2 |
Driving speed | 0-10km/h | Provide traction | 6KN |
Chassis model | ATV hydraulic rubber crawler chassis | Provide hydraulic source | 20L/m，210bar |
Engine | 20Kw@2400RPM Japan Yanmar turbocharged engine 20Kw@2400RPM | Optional function | Electric winch, pulling force greater than 1 ton |
Self-protection function | Water mist self-protection |
The RXR-M150GD is widely used in:
Forest fire suppression
Urban high-rise fire rescue
Industrial plant fire control
Chemical and oil refinery emergencies
Tunnel and underground fire rescue
DIY-friendly and disaster response operations
Reduces firefighter exposure to extreme danger
Improves large-scale fire suppression efficiency
Enables remote intelligent firefighting operations
Provides real-time fire scene data
Suitable for multi-environment emergency response
